Hammond Audio Übertrager 600 OHM 25 WATT 1626SEA

"Over designed" for high fidelity, single ended, Class-A, tube output circuits (triode, tetrode or pentode tubes).
Audio Watts: 25
Impedance: 600
Primary Max. DC: 250 ma.
Inductance: 2.9 Henrys
Ultra-Linear 40% Primary Tap: Yes
Secondary Impedance: 4-8-16
Hipot test (VRMS): 2000
Triodes: 6C33

156,15 €

inkl. 19% USt. , zzgl.

Unverbindliche Preisempfehlung des Herstellers: 168,24 €

(Sie sparen 7.19%, also 12,09 €)

ab	Stückpreis
10	153,75 €*
25	150,15 €*

"Over designed" for high fidelity, single ended, Class-A, tube output circuits (triode, tetrode or pentode tubes).
Enclosed (shielded), four slot, chassis Type "X" mounting.
Frequency response at least 20 Hz. to 20 Khz. at full rated power (+/- 1 db max., ref. 1 Khz.)
Insulated flexible leads 8" min.
For maximum versatility, all units (except the 1642SE & 1638SEA) include a 40% screen tap for Ultra-Linear, tetrode/pentode operation (if desired). The 1642SE & 1638SEA do NOT include this screen tap as they were designed principally for high impedance triode tubes.
High quality laminations, (M6) grain oriented silicon steel.
Core is gapped to reduce core saturation in Class-A tube amplifier circuits.
For general purpose or replacement use in single ended tube output circuits see our 125SE Series.

Produkteigenschaft	Wert
Versandgewicht:	4,99 kg
Artikelgewicht:	4,99 kg
