Hammond Netztrafo 3.6VA 12V@0.3 266F12B

Artikelnummer: HA-266F12B
HAN: 623980024837
Kategorie: Hammond
Hersteller: Hammond

Primary 117/234 VAC, 50/60 Hz.
Secondary VAC R.M.S.
12V 0,3A
6V 0,6A
VA: 3,6

17,70 €

inkl. 19% USt. , zzgl.

Unverbindliche Preisempfehlung des Herstellers: 19,06 €

(Sie sparen 7.14%, also 1,36 €)

ab	Stückpreis
10	17,43 €*
25	17,02 €*

1 Auf Lager
Lieferzeit: 1 Tage (DE - Ausland abweichend)

Beschreibung
Bewertungen
PDF (1)

Primary 117/234 VAC, 50/60 Hz.

All units have dual secondaries except 266LA25 (C.T. secondary only). If you only require a single primary & secondary check out our more economical 166 Series.

Secondaries can be used as; a center tapped secondary, parallel connected or used individually (except 266LA25).

Units are designed for use with all windings engaged.

Open style.

Minimum 6" long leads.

Dual bobbin design - no electrostatic shield required.

We use Class B insulation (130 degrees, C) for extra protection - UL listed as a Class A (105 degree, C) design

Hi-Pot test of 2,000V RMS.

UL listed (# E207860) Type 3AH

CSA certified (209651)

Produkteigenschaft	Wert
Anwendung:	Netztransformator
Versandgewicht:	0,18 kg
Artikelgewicht:	0,18 kg
