Neutrik NP3TT-P-B Plug 0.173'' Bantam Type Miniature Plug

4,84 €
(4,07 € excl. vat)
Scale price:
  • from 20: 4,74 €*
  • from 50: 4,54 €*
  • from 100: 4,37 €*
* Price per unit
Scale price:
  • from 20: 4,74 €*
  • from 50: 4,54 €*
  • from 100: 4,37 €*
* Price per unit
including VAT., plus shipping
  • Delivery expected on 17.12.2021
  • Goods in transit: More than 10 are already reordered
  • Shipping time: 14 - 15 workdays
Order Now
Category
Manufacturer
Item no.
  • NP3TTP-B
Product weight
  • 0,01 kg
Shipping weight
  • 0,02 kg

Interesting items

  1. Neutrik NP3TT-P-R Plug 0.173 Bantam Type Miniature Plug
    Neutrik NP3TT-P-R Plug 0.173'' Bantam Type Miniature Plug
    4,84 €
    (4,07 € excl. vat)
    including VAT., plus shipping
  2. VU-Meter S-500 dB Compression White
    VU-Meter S-500 dB Compression White

    Average Rating: 5/55
    Special price: 35,44 €
    (29,78 € excl. vat)
    Old price: 39,73 €
    including VAT., plus shipping

Description

4.4 mm (0.173") tiny telefone plug bantam type, solder termination for T+R, hex crimp of S with a standard RG58 crimp tool, black plastic housing, Nickel contacts. Ideal use with TT patch panels.



Features & Benefits

  • Designed for pro audio applications
  • Robust egonomic design - long-lasting and depenable
  • Standard HEX crimp cable clamp for shield termination and cable retention
  • Colored sleeves available for coding and marking
Product
Title
NP3TT-P-B
Connection Type
Plug
Gender
male
Electrical
Contact resistance
depends on mating connector m?
Dielectric strength
1 kVdc
Insulation resistance
> 2 G? (initial)
Rated current per contact
depends on mating connector A
Rated voltage
< 50 V
Mechanical
Cable O.D.
4 - 4.8 mm
Crimp size
5,41 Hex crimp (shield) acc. IEC 60803 (die designation D)
Lifetime
> 1000 mating cycles
Wiresize
0,25 mm²
Wiresize
24 AWG
Wiring
Solder contacts
Material
Contact plating
2 µm Ni (Su)
Contacts
Bronze (CuSn6) (Tip)
Shell
Polyamide (6 30% GR) (black)
Insulation
Polyamide (PA 6.6 30 % GR)
Environmental
Standard compliance
MIL-P-642/13
Solderability
Complies with IEC 68-2-20
Temperature range
-20 °C to +65 °C
